Oracle Database Appliance (Original Version) Hot-Swappable Components
Appliance X4-2, or Oracle Database Appliance X5-2, go to
X4-2/X5-2 Server Node Hot-Swappable Components" on page 39
Appliance X3-2/X4-2/X5-2 Storage Shelf Hot-Swappable Components" on page
Hot-swappable components are those that can be removed and installed while the system and
the server nodes are running without requiring any administrative tasks.
Note -
or SAS cable), you should wait before performing the next action to allow the system software
to fully process the event. This could take up to 3 minutes to complete.
In Oracle Database Appliance (original version), the following devices are hot-swappable:
Storage and Boot Drives. See
■
(CRU)" on page
Fan modules. See
■
Power supplies. See
■

Servicing Storage Drives and Boot Drives (CRU)

Oracle Database Appliance (original version) has 24 storage drives, located in the front of the
chassis, and each server node has 2 boot drives, located in the rear. All storage drives and boot
drives are hot-swappable.
See "Storage and Boot Drive Status Indicators" on page 21
status LEDs.
This section includes:
"Storage and Boot Drive Locations" on page 48
■
"Remove a Storage Drive" on page 50
■
"Install Storage Drive" on page 51
■
"Remove a Boot Drive" on page 52
■
"Install a Boot Drive" on page 53
■

Storage and Boot Drive Locations

Appliance storage drives. Appliance storage drives are installed at the front of Oracle
Database Appliance (original version). Drive numbering is listed on the drive label on the right
side of the appliance [1].
48 Oracle Database Appliance Service Manual • February 2016
After a physical insertion or removal action of a storage shelf component (such as a disk
48.
"Servicing Fan Modules (CRU)" on page
"Servicing Power Supplies (CRU)" on page
"Servicing Storage Drives and Boot Drives
"Oracle Database Appliance X3-2/
or "Oracle Database
40.
54.
57.
for specific information about drive
