Oracle Database Appliance Service Manual page 116

Install Disk Midplane Module HDD Cable
See
b. Disconnect the power cords from the system.
If the system is installed in a rack, remove it.
c.
See the Oracle Database Appliance Owner's Guide for instructions.
Attach an antistatic wrist strap.
d.
See
2. Remove the middle section of the system top cover.
See "Removing the Middle Section of the System Top Cover" on page
Disconnect the HDD ribbon cable connector located on the power distribution
3.
board [1]).
Disconnect the HDD ribbon cable connector located on the disk midplane
4.
module [2].
Install Disk Midplane Module HDD Cable
1. Reconnect the HDD ribbon cable connector located on the disk midplane module
[2]).
116 Oracle Database Appliance Service Manual • February 2016
"Shutting Down a Server Node and Powering Off the System" on page
"Performing Electrostatic Discharge and Antistatic Prevention Measures" on page
31.
34.
36.
