Installing the Wall and Column Brackets
Combining column and wall brackets
Pax-i3D Smart(PHT-30LFO) Installation Manual
4 Installing the Equipment: Floor Standing (Optional)
1. Remove the middle carrying handle.
2. Move the equipment to installation site near the
wall.
3. Prepare the column bracket
COLUMN
BRACKET
4. Assemble the column bracket to the top of the
column with four flat head screws.
FLAT HEAD
SCREWS
Cross head
screw driver
with magnetic
tip
1. Prepare the wall bracket.
WALL
BRACKET
Part No.: 22
M5 x 12
Part No.: 29
4 PCS
Part No.: 36
55
