  • Page 5: Notice

    Notice Notice This manual covers the installation procedures for the PaX-i Plus / Insight dental X- ray unit. The Installation Manual and the User Manual are shipped with each hardware unit. Brand name: PaX-i Plus / Insight (Model: PCH-30CS) Manufactured by: VATECH Co., Ltd.

  • Page 6: Important Notes

    Failure to read and understand the information provided in this manual may result in physical injury, damage to the equipment or equipment failure. Please read each CHAPTER in its entirety and understand the information therein before attempting any of the installation procedures. PaX-i Plus / Insight Installation Manual...

  • Page 7: Table Of Contents

    Installing the CEPH Unit (Optional) ..........52 Fixing the Base (Optional) .............. 55 Connecting the Cables to the Equipment......... 58 Leveling the Equipment ..............60 4.10 Tightening the Bolts ............... 63 Installing the Equipment: Wall Mount ..........65 PaX-i Plus / Insight Installation Manual...

  • Page 8: Table Of Contents

    Environmental Specifications ............122 Appendix A ....................123 Installing the Warning Lamp and Door Interlock Switch ....123 Installing the Emergency Stop Switch ..........126 Limiting the Column Height ............127 Connecting the 3 party Exposure Switch (Optional) .......131 PaX-i Plus / Insight Installation Manual...
  • Page 9 Table of Contents Checking PC BIOS Settings ............132 Installation Checklist ..............133 PaX-i Plus / Insight Installation Manual...
  • Page 10 Table of Contents PaX-i Plus / Insight Installation Manual...

  • Page 11: Introduction

    1. Introduction Introduction Manufacturer's Liability As the manufacturer, VATECH assumes liability for the safe and reliable installation and operation of this equipment only when:  Equipment installation, including software installation, was carried out by an authorized agent in accordance with this installation manual.

  • Page 12: Conventions In This Manual

    Emphasizes important information or provides NOTE useful tips and hints. Indicates a possible danger from exposure to RADIATION radiation. Indicates that an item is susceptible to damage from electrostatic discharges. susceptibility PaX-i Plus / Insight Installation Manual...
  • Page 13 Do not use the electrical power drill during installation unless it is allowed to do so. Do not use the electrical power drill during installation unless it is allowed to do so. PaX-i Plus / Insight Installation Manual...
  • Page 14 Recommended holding area during transportation is as below. Three installers are required to install the equipment safely. The Main Power Switch and Emergency Stop Switch are located under the bottom of the Vertical Frame as below. PaX-i Plus / Insight Installation Manual...
  • Page 15 Do not connect any items or equipment to this system which are not part of the system: IEC60601-1-1 (3 edition: 2005).  Any equipment not approved by VATECH must comply with the applicable standards: IEC 60950-1 (2 edition: 2005) for IT equipment (Ex: PC) and IEC 60601-1 (3 edition: 2005) for medical electrical equipment.
  • Page 16 Exposure Switch and observe the patient and capture-progression.  Operators must provide protective clothing to the patient before X-ray capturing. Pregnant women must consult with a doctor prior to being exposed to an X-ray. PaX-i Plus / Insight Installation Manual...
  • Page 17  Any equipment not provided by VATECH can be connected when the following standards are complied with: IEC 60950-1 and IEC 60601-1 ...

  • Page 18: Marks And Symbols

    Devices 93/42/EEC as amended by 2007/47/EC as a class IIb device. CSA mark Label No.266436 Caution: Federal law restricts this device to sale by or on the Label order of a licensed healthcare practitioner. PaX-i Plus / Insight Installation Manual...
  • Page 19 ED.2 regulations. Indicates that the user needs to refer to the Instruction Label Manual. Indicates the date of Label manufacture. Indicates the manufacturer's serial number so that the Label specific equipment can be identified. PaX-i Plus / Insight Installation Manual...

  • Page 20: Standards And Regulations

    1. Introduction Standards and Regulations Standards PaX-i Plus / Insight (Model: PCH-30CS) is designed and developed to comply with the following international standards and regulations:  IEC 60601-1, IEC/EN 60601-1-2, IEC 60601-1-3, IEC 60601-1-6, IEC 60601-2-63  CAN/CSA-C22.2 No. 60601-1:14, CAN/CSA-C22.2 No. 60601-1-3:09, CAN/CSA- C22.2 No.

  • Page 21: Choosing An Installation Site

     The PC monitor, emergency cut off switch and X-ray Exposure Switch should be installed in the vicinity of the operator so that he or she can manage them simultaneously in case of emergency. PaX-i Plus / Insight Installation Manual...
  • Page 22 2. Choosing an Installation Site <Without CEPH Unit (optional): 2,200 mm (L) x 1,400 mm (W) or wider > PaX-i Plus / Insight Installation Manual...
  • Page 23 2. Choosing an Installation Site <With CEPH Unit (optional): 2,200 (L) x 2,200 mm (W) or wider > <Ceiling Height: 2,600 mm (H) or higher > PaX-i Plus / Insight Installation Manual...
  • Page 24 2m (7’) from the source of the radiation.  Maintain visible contact with the patient and a clear view of indicators such as the warning lamp and imaging status on the PC. PaX-i Plus / Insight Installation Manual...

  • Page 25: Specifications For Electrical Installation

    Mode of operation: Continuous operation with intermittent loading - Needs waiting time (at least 60 times the exposure time) before next exposure begins.  Column operation time: Max. 2 min. On / 18 min. off (Ratio 1:9) PaX-i Plus / Insight Installation Manual...
  • Page 26 Exposure Time (s) ± (5 % + 50 ms) according to IEC 60601-2-  The mains resistance should not exceed 0.045 ohm at 100 V and 0.19 ohm at 240 V. This equipment should be connected to the earthed outlet. PaX-i Plus / Insight Installation Manual...

  • Page 27: Environmental Specifications

    During Operation Relative humidity 30 ~ 75 % Atmospheric pressure 860 ~ 1060 hPa -10 ~ 60 ℃ Temperature During Transport Relative humidity 10 ~ 75 % and Storage Atmospheric pressure 860 ~ 1060 hPa PaX-i Plus / Insight Installation Manual...

  • Page 28: Exposure Switch Installation Options

    The user operates the Exposure Switch from inside the X-ray room. Option No. 2: The user operates the Exposure Switch from outside the X-ray room. The Exposure Switch holder is mounted on the wall. PaX-i Plus / Insight Installation Manual...
  • Page 29 2. Choosing an Installation Site Option No. 3: The 3 party Exposure Switch (not VATECH’s) is used on demand of the customers. For this scenario, see the Appendix D “Connecting the 3 party The Exposure Switch” for details. PaX-i Plus / Insight Installation Manual...

  • Page 30: Installation Versions

    2. Choosing an Installation Site Installation Versions Base-stand Type PaX-i Plus / Insight Installation Manual...
  • Page 31 2. Choosing an Installation Site Wall-mount Type PaX-i Plus / Insight Installation Manual...

  • Page 32: Installing The Warning Lamp And Door Interlock Switch

    Install the Emergency Stop Switch along the main power cable in the central distribution panel  Install this switch so that it is within easy reach of the operator but cannot be accidentally pressed.  The switch must be a fool-proof model. PaX-i Plus / Insight Installation Manual...

  • Page 33: Before Installing The System

    Before or during the system installation, make sure that you use the checklist No.3 through No.6 in the Appendix F. Installation Checklist. Required Tools The following tools are necessary to install the PaX-i Plus / Insight. Item Figure Size 1.5 mm -10 mm Wrench Set (0.06”...
  • Page 34 : for Wall Mount type Marker Pen (thick tip) : for Wall Mount type Hammer : for Wall Mount type Multimeter Hammer Drill L = 200 mm (7.9”) for Wall Mount type Transport Dolly PaX-i Plus / Insight Installation Manual...

  • Page 35: Checking The Shockwatch And Tiltwatch Indicators

    Locate the ShockWatch and TiltWatch indicators and check if they have been activated. If either the packaging is damaged or the ShockWatch or TiltWatch indicators have been activated, please do not open the package and immediately contact the shipping company, agent or VATECH. PaX-i Plus / Insight Installation Manual...

  • Page 36: Unpacking Boxes

     All packaging and Styrofoam used to ship this equipment is recyclable.  Return the packaging to VATECH representatives or dispose of it in compliance with the legal regulations of your country. 3.3.1 Box No. 1 - Main Box Component...
  • Page 37 Remove the Top Cover. Remove a single side cover. In case of unabling to lift the side cover up fully, due to ceiling height, cut the box in half using the utility knife instead. PaX-i Plus / Insight Installation Manual...
  • Page 38 Do not discard thease EPS (A, B), so that they are reused later when the CEPH unit is installed. Separate two side EPS (A, B). The resulting view is as follows. Remove the case column front cover PaX-i Plus / Insight Installation Manual...
  • Page 39 3. Before Installing the System  The view after removal of the EPS is as below. PaX-i Plus / Insight Installation Manual...
  • Page 40 Weight (kg / lbs) 1046 (L) x 1056 (W) x 185 (H) / Base 47 / 103 41" (L) x 41.5" (W) x 7" (H) Removing the cover Open the box cover, the Base Cover is appeared. PaX-i Plus / Insight Installation Manual...
  • Page 41 3. Before Installing the System Remove the upper box, the Base Unit is appeared. PaX-i Plus / Insight Installation Manual...
  • Page 42 Weight (kg / lbs) 1590(L) x 820(W) x 870(H) / CEPH unit 50 / 110 62.6"(L) x 32.3"(W) x 34.3"(H) Removing the cover Open the box cover and remove the packing material as shown in the figure. PaX-i Plus / Insight Installation Manual...

  • Page 43: Checking The Parts

    3. Before Installing the System Checking the Parts 3.4.1 Location Layout of the Parts and Accessories PaX-i Plus / Insight Installation Manual...
  • Page 44 Switch Holder Double Sided Yes □ No □ Sticker Yes □ No □ Screws M3X16 Yes □ No □ Hand Plate Carpus Handrest Yes □ No □ Sticker Plate Align Yes □ No □ Wall PaX-i Plus / Insight Installation Manual...
  • Page 45 Left Blank Intentionally CEPH Option Yes □ No □ For Ear Rods 2 + 2 (2: on the equipment) For Nasal CEPH Option: Yes □ No □ Silicon Cover Positioner extra Left Blank Intentionally PaX-i Plus / Insight Installation Manual...
  • Page 46 Yes □ No □ Wrench Bolt w/ Spring and Flat Washers Yes □ No □ Wrench Bolt M10 x 25 M8 x 45 Yes □ No □ Wrench Bolt w/ Spring and Flat Washers PaX-i Plus / Insight Installation Manual...
  • Page 47 Yes □ No □ Sticker Yes □ No □ Ficher strong M10X40 anchor EAM8N column Yes □ No □ M10_L20 Wrench Bolt W/Spring Washer Yes □ No □ Ficher strong M8X30 wall anchor EAM8N PaX-i Plus / Insight Installation Manual...
  • Page 48 M8 x 25 w/ Wrench Bolt Spring and wall Bracket Flat Washers Yes □ No □ wall Bracket Yes □ No □ Wall Bracket 1 For Americal Yes □ No □ Wall Bracket 2 only PaX-i Plus / Insight Installation Manual...

  • Page 49: Installing The Equipment: Base Stand (Optional)

    Place some protective stuff on the floor to avoid the scratches on the surface.  One installer should keep on holding the Vertical Frame area to keep the equipment stable, after it is unloaded. PaX-i Plus / Insight Installation Manual...
  • Page 50 Then put the cables down on the floor carefully. Be careful not to damage the cables or have the column surface scratched. Assemble two wrench bolts as shown as below. M10 x 25 Wrench Bolt (Part No. 24) PaX-i Plus / Insight Installation Manual...
  • Page 51 4. Installing the Equipment: Base Stand (Optional) Remove the carrying handle at the bottom of the column unit. Allen Wrench 6 mm / 0.24” PaX-i Plus / Insight Installation Manual...

  • Page 52: Assembling The Base With The Column Unit

    Assembling the Base with the Column Unit. Hang the base unit onto two bolts temporarily as shown as shown as below. An installer should hold the base unit to keep it from falling down. PaX-i Plus / Insight Installation Manual...
  • Page 53 8 mm / 0.3” M10 x 20 Wrench Bolt w/ Spring (Part No. 23) Put the bolts into the holes until about 20 mm are left outside. Tighten two Wrench Bolts firmly as shown as below. PaX-i Plus / Insight Installation Manual...
  • Page 54 Be sure not to damage the cables. Before erecting the equipment, keep them clear of the equipment. Tighten the three Wrench Bolts to attach the base unit. Allen Wrench 8 mm / 0.31” M10 x 20 w/ Spring Wrench Bolt (Part No.23) PaX-i Plus / Insight Installation Manual...

  • Page 55: Removing The Transportation Handle

    4. Installing the Equipment: Base Stand (Optional) Removing the Transportation Handle (without the CEPH unit) Remove the upper carrying handles. Allen Wrench 6 mm / 0.24” One installer should hold the handle, while the other is removing the bolts. PaX-i Plus / Insight Installation Manual...

  • Page 56: Installing The Wall And Column Brackets

    Attach the above bracket to the back of the column with the four Wrench Bolts. M8 x 20 w/ spring and Wrench Bolt flat washers (Part No. 29) Allen Wrench 6 mm / 0.24” PaX-i Plus / Insight Installation Manual...
  • Page 57 Combine the column and wall brackets in the following manner with the 2 Wrench Bolts. Allen Wrench 6 mm / 0.24” M8 x 25 w/ Spring and Flat Wrench Bolt Washers (Part No. 34) Monkey Wrench (Part. No. 34) Do not tighten the bolts fully yet. PaX-i Plus / Insight Installation Manual...
  • Page 58 Move the equipment to the installation site as close as possible. Adjust the distance between the wall and equipment by moving it slightly, so that the wall bracket touches the wall. Mark four anchor bolt locations on the wall. Marker PaX-i Plus / Insight Installation Manual...
  • Page 59 Drill the wall holes of size 10.5 mm x 30 mm (depth) using the concrete hammer drill. Remove the debris and clean the holes using the dust pump. Using the hammer, insert a Ficher strong anchor into the hole Ficher strong M8 x 30 anchor (Part No. 34) Hammer PaX-i Plus / Insight Installation Manual...
  • Page 60 Remove the middle carrying handle. If the CEPH unit is to be installed, this is used as the carrying handle. Do not detach it until indicated later after the equipment is moved to the installation site PaX-i Plus / Insight Installation Manual...

  • Page 61: Removing The Transportation Safety Bolts

    When removing the semi-transparent tape, be careful not to scratch the surface of the equipment. Remove the vertical top cover. Remove the safety lock bolt with a wrench. Allen Wrench 6 mm / 0.23” PaX-i Plus / Insight Installation Manual...

  • Page 62: Installing The Ceph Unit (Optional)

    Remove the plastic wrap covering the column unit and the tape for fixing the CEPH cables by using a cutter. Move and mount the CEPH unit on the Main Unit carefully, while observing the insertion state of 4 studs. PaX-i Plus / Insight Installation Manual...
  • Page 63 When fastening a bolt, make sure that the cable is not stuck on the surface.  When removing the semi-transparent tape, be careful not to scratch the surface of the equipment. Connect the cable between the CEPH unit and main unit. PaX-i Plus / Insight Installation Manual...
  • Page 64 Ensure that the caps of the fiber optic cable be removed Do not touch the tip of the fiber optic cable to prevent it from being dirty. Insert the fiber optic cable fully until the click sound is heard. PaX-i Plus / Insight Installation Manual...

  • Page 65: Fixing The Base (Optional)

    Before installing the equipment, put the base unit on the installation site and mark 2 locations on the floor Drill the floor holes of size 12mm x 30mm (depth) using the concrete hammer drill. Remove the debris and clean the holes using the dust pump. PaX-i Plus / Insight Installation Manual...
  • Page 66 4. Installing the Equipment: Base Stand (Optional) Secure the anchor bolts with the hammer. Place the base unit combined equipment on the proper position, lock the nuts and washers using ratchet wrench. PaX-i Plus / Insight Installation Manual...
  • Page 67 4. Installing the Equipment: Base Stand (Optional) Wooden Floor M12 x 70 Wood Screws (Part No. 34) L = 200 mm Hammer Drill (7.9”) Secure the base unit using the wood screws. PaX-i Plus / Insight Installation Manual...

  • Page 68: Connecting The Cables To The Equipment

    4. Installing the Equipment: Base Stand (Optional) Connecting the Cables to the Equipment. Connect the cables in the back of the column as shown in the figure. Cable No. Optic Cable H002040A (Part No. 21) Cable Tie (Part No. 20) PaX-i Plus / Insight Installation Manual...
  • Page 69 4. Installing the Equipment: Base Stand (Optional) Use the Cable Tie (Part No. 20) or Cable Holder (Part No.20) to fix the cables as shown below after the connection is completed. PaX-i Plus / Insight Installation Manual...

  • Page 70: Leveling The Equipment

    Turn the Rotating Unit clockwise so that the X-ray tube head faces the front as shown in the figure. Remove the case column front. Turn all screws on the base plate unit clockwise until they touch the ground. PaX-i Plus / Insight Installation Manual...
  • Page 71 Leveling Right and Left Place the Spirit Level, as shown in the figure. Adjust the base until the bubble on the Spirit Level centers in the middle, by turning left and right screws clockwise or vice versa. PaX-i Plus / Insight Installation Manual...
  • Page 72 When the leveling is completed, make sure that all eight set screws touch the floor by turning them clockwise if necessary. Assemble the vertical top cover. Assemble the case column front. PaX-i Plus / Insight Installation Manual...

  • Page 73: Tightening The Bolts

    4. Installing the Equipment: Base Stand (Optional) 4.10 Tightening the Bolts Tighten the joint bracket bolts. Allen Wrench 6 mm / 0.24” Monkey Wrench PaX-i Plus / Insight Installation Manual...
  • Page 74 4. Installing the Equipment: Base Stand (Optional) This page intentionally left blank PaX-i Plus / Insight Installation Manual...

  • Page 75: Installing The Equipment: Wall Mount

    You are advised to plan and study the installation environment carefully in advance before proceeding, since the installation involves drilling the wall and floor. Pre- installation planning is crucial to a successful installation. An accurate marking is of critical importance for a successful installation. Installation Overview PaX-i Plus / Insight Installation Manual...
  • Page 76 Put the align plate on the floor near the wall where the equipment should be installed as shown in the figure. Alignmnet (Part No. 4) Plate Mark 6 anchor bolts holes on the floor. Marker PaX-i Plus / Insight Installation Manual...
  • Page 77 Put the Ficher strong anchor bolts into the holes and attach them with the hammer. Verify that the Ficher strong anchor s are secured. Ficher strong M10 x 40 anchor (Part No. 34) L = 200 mm Hammer Drill (7.9”) PaX-i Plus / Insight Installation Manual...
  • Page 78 Put the equipment in a vertical position slowly while holding the upper handle as shown in the figure. Be careful not to damage the cables before erecting the equipment. Keep them clear of the equipment. PaX-i Plus / Insight Installation Manual...
  • Page 79 (Part No. 23)  Do not tighten the nuts until the leveling is completed.  While one installer is tightening the nuts, the other installers should hold the middle handle to prevent the equipment from falling. PaX-i Plus / Insight Installation Manual...

  • Page 80: Removing The Transportation Handle)

    Installing the CEPH Unit (Optional) Please refer to the section 4.6 Installing the CEPH Unit (Optional). Connecting the Cables to the Equipment Please refer to the section 4.8 Connecting the Cables to the Equipment. PaX-i Plus / Insight Installation Manual...

  • Page 81: Leveling The Equipment

    Prepare the Spirit Level. Turn the Rotating Unit clockwise so that the X-ray tube head faces the front as shown in the figure. Remove the column front.case PaX-i Plus / Insight Installation Manual...
  • Page 82 T-shaped Hex 8 mm / 0.3” Wench M10 x 20 Set Screw (Part No. 30) Put the Spirit Level on the location as shown in the figure. Leveling Right and Left PaX-i Plus / Insight Installation Manual...
  • Page 83 Leveling the Front and Back Assemble the vertical top cover. Turn each set screw clockwise or counterclockwise to make the equipment level while another person monitors the level indicator. Assemble the column front case PaX-i Plus / Insight Installation Manual...

  • Page 84: Tightening The Bolts

    5. Installing the Equipment: Wall Mount Tightening the Bolts Tighten the joint bracket bolts. Allen Wrench 6 mm / 0.24” Monkey Wrench Allen Wrench 8 mm / ” Tighten the nuts in the anchored bolts on the floor. PaX-i Plus / Insight Installation Manual...

  • Page 85: Completing Miscellaneous Works

    Assemble the base cover. Base Cover Fix the base cover with 3 truss bolts. M5 x 8 Truss Bolt (Part No. 26) Cross Head Screw Driver 6 mm / 0.24” w/ Magnetic PaX-i Plus / Insight Installation Manual...
  • Page 86 6. Completing Miscellaneous Works Cover the holes. (Cap1: 3, Cap2: 6) Base Caps 1 (Part No. 17) Base Caps 2 (Part No. 17) PaX-i Plus / Insight Installation Manual...

  • Page 87: Assembling The Temple Supports And The Chinrest

    Insert the normal Chinrest and the normal Bite Block into the unit. Chin (Part No.7) Block_High Chin_Bite (Part No. 8) Chin-Bite2 (Part No. 8) Insert the Temple Supports. Temple 1 set Supports (Part No. 5) 1 set Cap Ear ROD (Part No. 5) PaX-i Plus / Insight Installation Manual...

  • Page 88: Installing The Switch Holders

    Locate the Exposure Switch Holder with a sticker and three screws. Install the Exposure Switch Holder on the wall at the appropriate height using three screws. UP / DOWN Switch When installation of the Up/Down switch is completed, connect it to the following location. PaX-i Plus / Insight Installation Manual...

  • Page 89: Setting Up Pc

    Setting up PC Direct Connection Diagram Fiber Optic Cable - Used to transfer image data to the PC. Warning System Panel - Used to provide a visible indicator: Light on when the equipment is irradiating X-ray. PaX-i Plus / Insight Installation Manual...

  • Page 90: The Recommended Pc Requirements

    AVR (automatic voltage regulator) in order to keep the line voltage stable.  The PC system provided with the PaX-i Plus / Insight undergoes the rigorous test for software compatibility before shipping. Therefore, any later changes to the hardware and/or software may cause malfunction.
  • Page 91 Open the Start screen, type Windows Defender in the search box. Click the Windows Defender icon to start Windows Defender on the search result. Click Settings icon. On the Settings window, click Add an exclusion in Exclusions section. PaX-i Plus / Insight Installation Manual...
  • Page 92 7. Setting up PC On Select Folder window, type C:\VcaptureSW in the folder field and and click Exclude this folder. PaX-i Plus / Insight Installation Manual...

  • Page 93: Installing The Internal Peripherals

    Whenever handling the fiber optic frame grabber board: 1. Wear the ant-static glove. 2. Do not wear the likes of a thick jacket. The following figures and descriptions are based on the PC model Z440 from HP. PaX-i Plus / Insight Installation Manual...
  • Page 94 A bad insertion of the board into the PC slot could cause failure for Dark calibration data acquisition or noisy image acquisition. Put the slot holder back to its initial position. PaX-i Plus / Insight Installation Manual...

  • Page 95: Connecting The Cables To Pc

    (Part No. 21) Cable 3D Viewer (Part No. 1) License Key Remove the caps of the fiber optic cable. Connect the Fiber Optic Cable. Insert the 3D viewer 3D Viewer License Key into a USB port. PaX-i Plus / Insight Installation Manual...
  • Page 96 7. Setting up PC Confirm the the end result after connections is as same as below. The illustrations may differ from the actual product. PaX-i Plus / Insight Installation Manual...

  • Page 97: Setting Up Pc's Environment Variables

    In case the BIOS settings have not been configured in advance or the settings are different, however, please follow the steps below. Reboot the PC and go to BIOS setting mode. Set the variables as in the table below. PaX-i Plus / Insight Installation Manual...
  • Page 98 Power Options Runtime Power Management [Disable] Advanced Power Options Idle Power Savings [Normal] Advanced Power Options Enhanced Halt State (C1E) [Disable]  When you update the BIOS settings, “EnhancedHalt State (C1E)” option will be displayed. PaX-i Plus / Insight Installation Manual...

  • Page 99: Turning Off The Firewall

    On Windows Firewall screen, click the Turn Windows Firewall on or off. Select the Turn off Windows Firewall for both Home or work (private) and Public network location settings. Click OK to apply the settings. PaX-i Plus / Insight Installation Manual...

  • Page 100: Setting Up The Power Mangement Options

    Windows operating system. Disable the Screen Saver Open the Start screen, type Screen Saver in the search box. On Screen Saver Settings screen, select (None) in the pull-down menu. Click OK to apply the settings. PaX-i Plus / Insight Installation Manual...
  • Page 101 Open the Start screen, type Power Options in the search box. Click Choose when to turn off the display. Select Never for both Turn off the display and Put the computer to sleep fields. Click Save changes to apply the settings. PaX-i Plus / Insight Installation Manual...

  • Page 102: Turning Off The User Account Control

    Turning off the User Account Control Open the Start screen, type User Account Control in the search box. Disable the UAC by moving the slider bar down to the bottom, Never notify. Then, click OK to apply change settings. PaX-i Plus / Insight Installation Manual...

  • Page 103: Setting Folder Exclusions With Anti-Virus Software

     Always use the blank USB drive whenever possible. Some files used by the PaX-i Plus / Insight are incorrectly recognized as viruses / trojans by anti-virus software. If you are using anti-virus software on your PC, you must exclude those files from all scans performed by the anti-virus software.
  • Page 104 8. Setting up PC’s Environment Variables This page intentionally left blank. PaX-i Plus / Insight Installation Manual...

  • Page 105: Installing Software

    PC is the most up-to-date version. To check this, go to the Website: www. nvidia.com.  Perform virus scan for the PC and InstallPakage program with the anti-virus program prior to proceeding with its installation. PaX-i Plus / Insight Installation Manual...

  • Page 106: Software Installation Flow

    Installing Image Viewer Program One of the image viewer programs among EzDent-i or 3 party program must be installed at this time. For the details on the installation procedures, refer to the corresponding manuals. PaX-i Plus / Insight Installation Manual...

  • Page 107: Installing The Installpakage

    Insert the CD into the CD-ROM drive and then perform virus scan for the PC before installing the CD. Go to the InstallPakage folder and run Setup.exe. The following screen will appear. Click Next. PaX-i Plus / Insight Installation Manual...
  • Page 108 12. Check the options according to the product specifications. When the Auto Save is checked, the image data acquired saved automatically. 13. Confirm that the following drivers are selected. For the first time installation, select all. PaX-i Plus / Insight Installation Manual...
  • Page 109 14. You can check the information entered so far with the Ready to Install window. If necessary, you can modify it by clicking Back. 15. When the information is confirmed, click Install to continue. PaX-i Plus / Insight Installation Manual...
  • Page 110 9. Installing Software Installing the DirectX After completing DICOM viewer installation, DirectX® installation will be started. Select “I accept the agreement” in the Welcome window. PaX-i Plus / Insight Installation Manual...
  • Page 111 9. Installing Software Click Next to start installation. PaX-i Plus / Insight Installation Manual...
  • Page 112 9. Installing Software Click Finish to exit the wizard. PaX-i Plus / Insight Installation Manual...
  • Page 113 Installing the Frame Grabber (Virtual Serial 1.x) After completing Direct X® installation, Virtual Serial 1.x installation will be started.Click Install in the Welcome window. During installation, VA_4x Cap 1.x installation wizard will appear. Click Install to start installation. PaX-i Plus / Insight Installation Manual...
  • Page 114 (Optional) When Microsoft .NET Framework 4.x.x installation window appears, click Install to continue the process and click Finish when completed. When the Vitual Serial 1.x installation is completed, click Finish to exit the wizard. PaX-i Plus / Insight Installation Manual...
  • Page 115 Open the Start screen, type Uninstall a Program in the search box. Find the programs you want to uninstall and double-click the program to uninstall. When you are asked if you want to continue, click Yes or OK and follow the prompts to finish uninstallation. PaX-i Plus / Insight Installation Manual...

  • Page 116: Setting Up The User-Specific Information

    EzDent-i: Refer to section 9.5.1 when EzDent-i is installed. 9.5.1 When EzDent-i is installed Running the Image Viewer Run the image viewer. On your desktop, double-click EzDent-i icon. Its main window will be displayed. PaX-i Plus / Insight Installation Manual...
  • Page 117 Make sure that the console program settings are as follows:  Console Program Path: C:/VCaptureSW/exe/VCaptureSW.exe PaX-i Plus_Insight Captured  Capture Message:  Patient Information File Path: C:/VCaptureSW/PatientInfo.ini Click OK and restart the program to apply the settings. PaX-i Plus / Insight Installation Manual...
  • Page 118 Enter the required patient information. Chart Number, First Name, and Last Name are required fields which must be filled in. All other fields are optional, but it is recommended that they be filled in. Click Add to save the patient record. PaX-i Plus / Insight Installation Manual...
  • Page 119 See the section 9.5.3 Configuring the parameters > Disabling the packing mode to disable packing mode Proceed to the section 9.5.3 Configuring the parameters. PaX-i Plus / Insight Installation Manual...
  • Page 120 From the main GUI window, click the the settings icon on the upper right corner. Log in tap will be open as default. On the right side of the screen, select Engineer and type the password ('vatech') and then click Log In. Click User tab.
  • Page 121 Set the DAP (Dose Area Product) Level and DAP Unit for the unit which are displayed on the screen. In the Language Option, change the language if necessary and click Machine Set. Click General tab and type the serial number of the equipment in the Machine information. PaX-i Plus / Insight Installation Manual...
  • Page 122 In the Patient Information Setting, configure Link Type and File Path as shown below. In the Database & Linking, configure Link Type and File Extension as follows. Fields When EzDent-i is used CT / CR Link Type SDK Link CR Save Name PaX-i Plus / Insight Installation Manual...
  • Page 123 9. Installing Software 10. Click Default Set tab and configure the user-defined parameters. The default feature can be modified, according to the user’s requirement. 11.Click Save if changes occurred. PaX-i Plus / Insight Installation Manual...
  • Page 124 – serial port emulators. If necessary, change the COM port in the Networking option and click Save. Enter the command PVER] to verify the current mode. Note that the equipment is now in packing mode. PaX-i Plus / Insight Installation Manual...
  • Page 125 Use the command: PKEN_0001] to re-enter the packing mode, use. Click Exit button and terminate the control panel. Exit the imaging program (main GUI): important! Restart the equipment to take the changes into effect. PaX-i Plus / Insight Installation Manual...
  • Page 126 : Enter the command [SPM_MPOP_0001] in the command field, followed by Send. < When the same Beep Announcement is desired for PANO and CEPH imaging modality > : Enter the command [SPM_MPOP_0002] in the command field, followed by Send. PaX-i Plus / Insight Installation Manual...
  • Page 127 9. Installing Software Finalizing the Parameters Settings Click Exit → Close button and terminate the control panel. Exit the imaging program (main GUI): important! Restart the equipment to take the changes into effect. PaX-i Plus / Insight Installation Manual...
  • Page 128 9. Installing Software This page intentionally left blank PaX-i Plus / Insight Installation Manual...

  • Page 129: 10. Technical Specifications

    1910 mm (L) x 1200 mm (W) x 2272 mm (Length x Width x (H) (without Base) Height) With CEPH unit 1910 mm (L) x 1200 mm (W) x 2300 mm (H) (with Base) Rotating Unit Vertical Movement Max. 700 mm PaX-i Plus / Insight Installation Manual...
  • Page 130 10. Technical Specifications Item Description Base Stand / Wall Mount Installation type (Default: Wall Mount type) Main Box, CEPH Box (Optional), Base Packing Box Organization Box (Optional) PaX-i Plus / Insight Installation Manual...

  • Page 131: Electrical Specifications

    Mode of operation: Continuous operation with intermittent loading waiting time (at least 60 times the exposure time) before the next exposure begins.  Column operation time: Max. 2 min. On / 18 min. Off (Ratio 1:9) PaX-i Plus / Insight Installation Manual...

  • Page 132: Environmental Specifications

    During Operating Relative humidity 30 ~ 75 % Atmospheric pressure 860 ~ 1060 hPa -10 ~ 60 ℃ Temperature During Transport Relative humidity 10 ~ 75 % and Storage Atmospheric pressure 860 ~ 1060 hPa PaX-i Plus / Insight Installation Manual...

  • Page 133: Installing The Warning Lamp And Door Interlock Switch

    MEIGaN guideline. MEIGaN: Medical Electrical Installation Guidance Notes Pre-installation planning is crucial to a successful installation for these devices. For the further details, refer to the accompanying volume: Specification for Electrical Installation Block Diagram PaX-i Plus / Insight Installation Manual...
  • Page 134 Appendix A Schematic Diagram Components Supplied PaX-i Plus / Insight Installation Manual...
  • Page 135 Install the Warning System Panel at the proper height after taking each cable length into account. Connect the warning lamp (not provided). Connect the door interlock switch (not provided). Connect the power source for the warning lamp. PaX-i Plus / Insight Installation Manual...

  • Page 136: Installing The Emergency Stop Switch

    The cable sizes: N, L and PE≥ 12 AWG (3 x 4 mm The cable to Emergency Stop Switch shall be the same size as the power cable itself. Install the socket connector terminal for the 2nd protective ground wire. PaX-i Plus / Insight Installation Manual...

  • Page 137: Limiting The Column Height

    Measure the ceiling height in the X- ray shield room : H ceiling < Removing the column covers > Remove three Fixing Bolts as shown in the figure. Remove the Column Rear-Top Cover as shown in the figure. PaX-i Plus / Insight Installation Manual...
  • Page 138 Appendix A Remove the side cover. PaX-i Plus / Insight Installation Manual...
  • Page 139 (e.g. If d = 30 cm, H = 250 cm (99”), h -d = 250-30= 220 cm. ceiling screw height ceiling Accordingly, set the height to this level by using the height adjustment bolt. PaX-i Plus / Insight Installation Manual...
  • Page 140 Looking up the scale, slide the Limit Block down to new location (H = 220 mm) screw height and fix it back. Put the covers back in reverse order and fix them with the bolts. PaX-i Plus / Insight Installation Manual...

  • Page 141: Connecting The

    Cut the Exposure Switch cable provided with the equipment. According to the following schematic diagram, rewire the cables. Double-check the wiring before use. Tape the end of each unused wire to prevent the wires from causing an inadvertent short circuit PaX-i Plus / Insight Installation Manual...
  • Page 142 PC Model: HP Z440 PC BIOS default Main Menu Sub1 Menu Sub2 Menu Setup Value Advanced Power Options Runtime Power Management [Disable] Advanced Power Options Idle Power Savings [Normal] Advanced Power Options Enhanced Halt State (C1E) [Disable] PaX-i Plus / Insight Installation Manual...
  • Page 143 F. Installation Checklist 1. General Information: Customer Information about the Equipment Purchaser Name of Clinic or Hospital Address Phone E-Mail Web site Dealer Information about the Equipment Seller Name of Dealer Address Phone E-Mail Web site PaX-i Plus / Insight Installation Manual...
  • Page 144 Is the freight elevator available? Is the security guard, if any, notified of the installation in advance? Are two installers, including the helpers, available to move and unload the equipment? PaX-i Plus / Insight Installation Manual...
  • Page 145 Did delivery company carry and handle with caution? Did installers take pictures of boxes before opening? Did installer make sure there are not any suspicious holes or scratches on the box? Is the ShockWatch indicator red? Is the TiltWatch indicator red? PaX-i Plus / Insight Installation Manual...
  • Page 146 Did installers not touch or place pressure on sensors while installing? Did installer make sure harness and equipment are well connected and not damaged? Did installers check if the emergency button (switch) is working properly? Did the equipment be well balanced? PaX-i Plus / Insight Installation Manual...
  • Page 147 Type: Are the 3 party software installed? If yes, indicate name(s) and versions. Are they compatible with software from Vatech®? If No, Version: indicate name(s) and versions. 8. Electrical Requirements: Is the circuit breaker installed and tested in distribution panel for over-current protection w/ 20A? ≤...
  • Page 148 Is network configured with 1 Gbit/s of CAT5? Is the equipment connected with network? Is the network installation company identified? What is the TCP/IP address assigned? Address: What is the subnet masking address? Address: Is there DHCP server? PaX-i Plus / Insight Installation Manual...
  • Page 149 No part of this manual may be reproduced, transmitted, or transcribed without the expressed written permission of the manufacturer. We reserve the right to make any alterations which may be required due to technical improvement. For the most current information, contact your VATECH representative. Tel: (+82) 1588-9510 Email: gcs@vatech.co.kr Website: www.vatech.co.kr...
  • Page 152 0207: 화면교체함 0913KW: 예전 이미지임. Vcapture 화면 캡쳐 필요 0913KW: 예전 이미지임. Vcapture 화면 캡쳐 필요 0913KW: 확인 필요 0913KW: 예전 이미지임. Vcapture 화면 캡쳐 필요 0913KW: 예전 이미지임. Vcapture 화면 캡쳐 필요. 0913: Save button  Save 0808: 추가 0913KW: 예전...

This manual is also suitable for:

Pax-i insightPch-30cs

Table of Contents
