2.2
Specifications for Electrical Installation
These specifications are based on the MEIGaN (Medical electrical installation guidance notes).
Consult the companion manual for further information. : Volume 3: Specification for Electrical
Installation.
2.3
Electrical Requirements
Power supply voltage
● The input line voltage depends on the local electrical distribution system.
● Allowable input voltage fluctuation requirement: ± 10 %.
Frequency
Phase
Power rating (maximum power consumption)
Pax-i3D Smart(PHT-30LFO) Installation Manual
This equipment must be connected to a grounded outlet to fulfill the safety
provisions specified in IEC 60364: the 2
It is mandatory that both PC and equipment use the same power line if
connected to an MPSO.
Whenever possible, use different power outlets for each device. If a
multiple portable socket outlet (MPSO) must be used, ensure that the PC
and equipment are connected to the same MPSO.
Use a dedicated power outlet for the power cord. Failure to do so may
result in unstable system operation caused by power fluctuations.
It is strongly recommended that you install an AVR. An AVR (automatic
voltage regulator) maintains a constant voltage and allows for continuous
operation in the event of a power fluctuation.
2 Choosing an Installation Site
nd
edition (2006).
AC100-240 V
50/60 Hz
single
Max.2.2 kVA (during exposure)
23
