3.3
Unpacking the Boxes
Box No.1: Main box
Components
Size(mm/inch)
Weight(kg/lbs)
Pax-i3D Smart(PHT-30LFO) Installation Manual
All packaging and Styrofoam used to ship this equipment is recyclable.
Return the packaging to VATECH representatives or dispose of it in
compliance with the legal regulations of your country.
● Column and Rotating unit assembly
● Accessories and parts
● PC system(optional)
2170(L) x 905(W) x 1510(H) / 85.4"(L) x 35.6"(W) x 59.4"(H)
265/584
Main box
3 Before Installing the System
1510/59.4"
33
