Pax-i3D Smart(PHT-30LFO) Installation Manual
5 Completing Miscellaneous Works
Base cover(optional)
1. Assemble the base cover and fix it with three
truss bolts(Part No: 26).
2. Cover 3 holes on the base with three silicon
caps(Part No: 17)
Base front cover
1. Assemble the base front cover to the column.
69
