8 Installing Software
8.5.3

Configuring the parameters

The following information should be entered, in accordance with the user
requirements
1. From the main GUI window, click the icon highlighted by the red box.
2. Select Engineer and type the password('vatech') and then click Log In.
3. Click User tab.
4. Set the Label name in the Image Label Option. When Use Label is checked, the character
string in Label Text field is displayed on the left of the image. By default, the equipment name is
displayed.
5. Set the DAP(Dose Area Product) Level and DAP Unit for the unit which are displayed on the
screen.
116
Pax-i3D Smart(PHT-30LFO) Installation Manual
