Marks & Symbols
Symbols
Alternate current
Attention: consult accompanying documents
Dangerous voltage
Protective earth (Ground)
Off (power: disconnect from the main switch)
On (power: connect to the main switch)
TYPE B Equipment
Radiation hazard
EC REP EC representative
The CE symbol indicates that this product complies with
the European Directive for Medical Devices 93/42/EEC as
amended by 2007/47/EC as a class IIb device.
This equipmentis UL-marked according to UL60601-1 and
CAN/CSA C22.2 No. 601.1
Address where the equipment was manufactured
This symbol indicates that electrical and electronic
equipment must not be disposed of as unsorted municipal
waste and must be collected separately.
This symbol warns the user to take precautions when
dealing with electronic components which are sensitive to
static charges
This symbol indicates that this equipment is classified as
a CLASS 1 LASER PRODUCT in accordance with IEC
60825-1 ED.1 regulations.
