5 Completing Miscellaneous Works

5.2 Assembling Temple and Chin Supports

70
1. Insert the normal bite block into the chinrest.
Part No.: 13
BITE BLOCK:
NORMAL
1 PCS
2. Insert the temple supports and ear rod caps.
Part No.: 5
TEMPLE
SUPPORT
2 PCS(R, L)
Pax-i3D Smart(PHT-30LFO) Installation Manual
