5. Select the equipment mode: PaX-i3D Smart and click Next.
6. Select the modality and click Next. Note that if the CEPH feature comes with the equipment, also
check the CEPH.
7. Select the CT sensor type: WidePano and click Next.
8. Select the PANO sensor type: WidePano and click Next.
9. (Optional) Select the CEPH sensor: Anyceph(Scan type) or RTroy(Oneshot type) and click Next.
10. Select the default port number: COM4.
Select the port No.: COM4
The same COM port No. should be used between the equipment and PC.
And click Next.
11. Select the language and click Next.
12. Select the third-party software in use and click Next.
When EasyDent4 is installed, select EasyDent4, when EzDent-i is installed, select SDK.
EzsyDent4
EzDent-i
Click Next to continue.
