3 Before Installing the System
1. Move the main box to a convenient place as close as possible to the installation location
A
TOP
B
34
D
E
C
Bottom
2. Separate the top cover after removing the
strapping bands.
3. Lift up a small distance and remove the side
covers.
A: PC system (Optional)
B: PE foam
C: PE foam
D: Accessory and part box1
E: Accessory and part box2
Pax-i3D Smart(PHT-30LFO) Installation Manual
