4. Click OK.
Note: When you turn off MultiLogPRO, it will save the setup for the next session.
2.5.2.

Start Recording

Click Run on the main toolbar. Click the down arrow to change the
recording mode.
2.5.3.

Stop Recording

Click Stop on the main toolbar.
2.5.4.

Clear MultiLogPRO's Memory

To erase all experiment data currently stored in the MultiLogPRO, click Clear
memory in the Logger menu.
2.5.5.

Edit MultiLogPRO's Experiment Notes

1. Connect MultiLogPRO to the PC.
2. Select Edit notes from the Logger menu to open the Notes dialog
box with the MultiLogPRO's current experiment's notes downloaded
to the window.
3. From this dialog box, you can edit, delete, or write new notes.
Note: An experiment note is limited to 140 characters and a maximum of 5 notes can
be stored in MultiLogPRO at any time.
4. Use the arrow buttons to move to the next note, or to the previous
one.
5. Click OK to upload the edited notes to MultiLogPRO.
60 Chapter 2 MultiLab Software
Figure 15: Edit experiment notes dialog box
