4.
Start Recording
Click Run
on the toolbar to start recording.
If the recording rate is 100 measurements per second or less, MultiLab automatically
opens a graph window displaying the data in real time, plotting it on the graph as it is
being recorded. If the recording rate is higher than 100/s, the data will be
downloaded and displayed automatically, once the data recording is finished.
If you are recording at a rate of 500/s or 1,000/s, MultiLab displays an online preview
at a rate of 25/s.
You can stop recording anytime by clicking Stop
4.4.2.
Data recording options
To set the behavior of the data display when you start a new recording session, click
on the down arrow next to the Run button
1.Single measurement
MultiLab will open a new project file every time you start a new recording session.
2. Replace
MultiLab will display the new data set in place of the old one. The project's old data
sets will still be available in the same project file. They will be listed in the Data Map
and you can add them to the display at any time
3. Add
MultiLab will add the new data set to the graph in addition to the old ones.
Note: A maximum of 8 data sets can be displayed on the graph at the
same time.
4.4.3.
Online Video
MultiLab enables you to view online video of your experiment along with the data
display, as well as to record video movies of the experiment and to replay them
simultaneously with the data graph. You can also add voice comments to the video
recordings.
To work with the video window your system should be equipped with a video camera.
To be able to record and play voice comments your system should be equipped with
a sound card, a microphone and a speaker.
1. Online video
The online video will start playing automatically when you open the video window.
Click Video
on the main toolbar to display the video window.
on the toolbar.
, and select one of the following:
Chapter 4 Working with a desktop computer
83
