3. Opening a Stored Movie

1. Click Video Analysis
2. Click Open Movie
toolbar)
3. Double click the movie you want to open

4. Saving a Video Motion Analyzer Project

1. Click Save
2. Type a name in the File name box and click Save

5. Opening a Video Motion Analyzer Project

1. Click Video Analysis
2. Click Open
3. Double click the Project you want to open
2.7.3.

Capturing a New Movie

There are two basic options for capturing video onto your computer from:
A device attached to your computer
•
An external source through a video capture board
•

1. From a Device Attached to your Computer

From a device attached to your computer (such as a Web cam), you can capture
video directly from the camera to your computer. Web cams are intended primarily to
feed video over some connection (the Internet, for example). They generally produce
lower video quality. With a Web cam, you can only record when the Web cam is
attached to the computer. If quality and versatility are not your main concern, this
may be the best solution for you.
To capture video from a Web cam:
1. Connect the Web cam to the computer
2. Click Video on the menu bar, then click Enable video
3. Click Video Analysis
Motion Analyzer module
on the main toolbar
on the Video Motion Analyzer toolbar (lower
on the main toolbar
on the main toolbar
on the main toolbar
on the main toolbar to open the Video
Chapter 2 MultiLab Software 79
