2.7. Video Motion Analyzer

2.7.1.

Overview

MultiLab's Video Motion Analyzer enables you to capture position and time from
video movies, convert this to data sets and analyze the data with all of MultiLab's
analysis tools the same way you would analyze data from the data logger. You can
capture one-body motion or two-body motion. You can select the origin and rotate
the coordinate system.
With the Video Motion Analyzer you can also capture video movies either directly
from video camera connected to the computer or from an external video source such
as VCR.
2.7.2.

Getting Started

1. Video Motion Analyzer Basics

Open the Video Motion Analyzer module
Click Video Analysis
Open a movie from MultiLab's movie library or capture a new movie
Capture position and time
• Scaling – Scale the video to the real world dimensions
•
Coordinate system – Set origin and axes direction
•
Step – Set the number of frames you will capture position and time
• Marking – Mark the position of the body on the frames. MultiLab will
automatically convert it to numerical data
Analyze the data
The captured data is automatically displayed in the graph and table windows.
Analyze it as you would normally with MultiLab's projects.

2. Saving a New Movie

1. After you have finished capturing a new video movie, click Analyze
movie
2. MultiLab prompts to save the movie
3. Type a name in the File name box and click Save
78 Chapter 2 MultiLab Software
on the main toolbar
to begin capturing position and time
