2.6. Analyzing the Data

2.6.1.

Reading Data Point Coordinates

Position the cursor (see page 44) on a point to display its coordinates on the
information bar at the bottom of the graph window.
If more than one curve is displayed, and you want to read the Y- coordinates of all of
the curves simultaneously, bring up digital meters (see page 51) for each of the
curves. When you position a cursor on one curve, the meters will show the
corresponding Y-coordinates for the other curves.
2.6.2.

Reading the Difference between two Coordinate Values

Position one cursor on the first point, and a second cursor on the second point to
display the difference between the two coordinate values on the information bar at
the bottom of the graph window.
2.6.3.

Working with the Analysis Tools

The analysis tools can only be applied to data sets that are displayed in the graph
window.
1. Use the cursors (see page 44) to select the graph and the data
range to which you want to apply the analysis.
2. Select the analysis function you wish to use.
The analysis function will be added onto the graph, with the exception of the
smoothing (averaging) function, which will replace the original data set.
To measure and analyze time events with photogates use the Timing Wizard (see
page 90).
2.6.4.

Smoothing

The smoothing tool is very useful in reducing random noises, especially if you want to
apply any analysis functions to the data. The smoothing process replaces every data
point with the average of its neighboring points.
1. Use the cursor to select the graph that you want to smooth.
2. Click More smoothing
3. You can repeat the procedure to further smooth the data.
4. Click Less smoothing
on the graph toolbar.
to reduce the amount of smoothing.
Chapter 2 MultiLab Software 65
