3.3. Getting Started

3.3.1.

Set up a Recording Session

1.

Prepare TriLog

1. Connect TriLog to the PC (see page 10)
2. Turn on TriLog
3. Plug in any external sensors
4. Open the MultiLab software
2.

Enable Video Recording

1. Connect the camera to the PC
2. Click Video
3. Point the camera to the experiment setup
3.

Setup the TriLog

1. Click Setup Wizard
2. Follow the instructions in the Setup Wizard (see page 66)
4.

Start Recording

Click Run on the toolbar to start recording.
If the recording rate is 100 measurements per second or less, MultiLab automatically
opens a graph window displaying the data in real time, plotting it on the graph as it is
being recorded. If the recording rate is higher than 100/s, the data will be
downloaded and displayed automatically, once the data recording is finished.
If you are recording at a rate of 500/s or 1,000/s, MultiLab displays an online preview
at a rate of 25/s.
You can stop recording anytime by clicking Stop
3.3.2.

Data recording options

To set the behavior of the data display when you start a new recording session, click
on the down arrow next to the Run button
on the main toolbar to display the video window
on the main toolbar
, and select one of the following:
Chapter 3 Working with MultiLab
on the toolbar.
51
