Online Video; Recording; Replaying An Experiment; Video And Audio Properties - Fourier MultiLogPRO User Manual

You can also perform manual logging via MultiLogPRO (see page 20).
2.3.4.

Online Video

MultiLab enables you to view online video of your experiment along with the data
display, as well as to record video movies of the experiment and to replay them
simultaneously with the data graph. You can also add voice comments to the video
recordings.
To work with the video window your system should be equipped with a video camera.
To be able to record and play voice comments your system should be equipped with
a sound card, a microphone and a speaker.
1. Online Video
The online video will start playing when you open the Video window. Click Video
on the main toolbar to display the video window and enable video (see page
31).

2. Recording

1. From the Video menu select Enable video
2. Click Record
video recording.
3. Click Run
4. Once the data logging has finished, click Stop Video Recording
.
5. Click Replay
video recording simultaneously.
Note: Saving the file will automatically save the video as well.

3. Replaying an Experiment

To simultaneously replay the video and the data graphing process of a saved file:
1. Open the file (see page 40)
2. Display the data on the graph (see page 51)
3. Click Replay

4. Video and Audio Properties

To set the video properties click Video on the menu bar, then click Video properties
to open the video properties dialog box:
on the right-hand side of the toolbar to start
to start data recording
to replay both the data graphing process the
Chapter 2 MultiLab Software 33
