The Distance and Force sensors properties include definition of the positive direction
and the distance sensor properties enable online averaging as this sensor is
comparatively noisy.
You can define the properties of each sensor individually in the first step of the Setup
wizard, or by selecting Calibrate sensors from the Logger menu.
1. Click Setup Wizard
wizard
2. Click Properties
3. Click the check boxes next to the desired measurements.
4. To change more properties, click the corresponding tab at the top of
the dialog box
5. Click OK.

3. Setting the Zero Point of a Sensor

MultiLab enables you to rescale some sensors and to set the current readings to
zero for subsequent loggings. This feature applies to the following sensors:
•
Distance
•
Force
•
Magnetic field
•
Light sensors
•
Pressure sensors
To set the current readings of a sensor to zero:
1. Click Setup Wizard
Wizard
2. Click Properties
3. Click the Set Zero tab
4. Check the Set the current reading to zero check box
5. Click OK
6. Click Finish
MultiLab takes a single measurement and set the reading to zero.
To change the zero point:
1. Click Setup Wizard
Wizard
56 Chapter 2 MultiLab Software
on the main toolbar to open the Setup
next to the input you want to set.
on the main toolbar to open the Setup
next to the input you want to set
on the main toolbar to open the Setup
