Multilab Installation; Windows Os (Instructions Based On Winxp) - Fourier MultiLogPRO User Manual

2.1.2.

MultiLab Installation

1. Windows OS (instructions based on WinXP)

Warning: Do not connect the supplied Web camera to the PC before you
install the MultiLab software.
Uninstalling MultiLab
Before installing your new version of MultiLab, uninstall any older versions of the
program.
Note: Uninstalling MultiLab removes program files only. Project files and worksheets
you created or modified in MultiLab will remain on your system and there is no need
to create backups.
To uninstall MultiLab:
1. From the Start menu select Settings then click Control Panel.
2. Double click Add or Remove Programs.
3. Select MultiLab from the list of programs.
4. Click Remove.
5. In the following dialog box, click Yes to confirm that you want to
remove MultiLab.
6. When uninstall is complete you will be prompted to restart the
computer. Select Yes.
To install MultiLab:
1. Close all programs.
2. Insert the CD labeled MultiLab into your CD-ROM drive.
3. The installation process will begin automatically and you will be
prompted to install MultiLab. Click Next to continue the installation.
Note: If auto run is not working, open My Computer and click on the CD drive folder
(d: drive in most cases) and double-click on the setup icon, then proceed as above.
4. Enter user name and company name in the Customer Information
window. Select the type of user for whom the application should be
installed. It is recommended to install for all users. Click Next.
5. In the Choose Destination Location window, the default folder
where MultiLab will be installed is C:\Program Files\Fourier
Systems\MultiLab\. Click Browse to change this folder location, or
click Next. MultiLab installation will proceed
6. When MultiLab (and associated components) installation is
complete, the Install Wizard will then install the D-Link Web cam
26 Chapter 2 MultiLab Software
