8. Add Annotations to the Graph

You can add annotations to the graph. An annotation is always connected to a
certain data point.
To view annotations:
Click Graph on the menu bar and then select Show annotation (this option is
usually selected by default)
To add an annotation:
1. Place a cursor on the desired point
2. Click Add new annotation
new annotation caption edit box
3. Type in the text, then click OK
To move an annotation:
1. Click Move annotation
2. Click on the annotation you want to move, then drag if to the new
position
3. Click Move annotation
annotation mode
To edit an annotation:
1. Place a cursor on the point to which the annotation is connected
2. Click Graph on the menu bar, then click Edit annotation
3. Edit your annotation, then click OK
To delete an annotation:
1. Place a cursor on the point to which the annotation is connected
2. Click Graph on the menu bar, then click Delete annotation
To hide all annotations:
Click Graph on the menu bar and then click Show annotation to uncheck it.
48 Chapter 2 MultiLab Software
on the graph toolbar to display the
on the graph toolbar
a second time to exit the move
