Chapter 5
Specifications

5.1. The MultiLogPRO Data Logger

Input
Auto ID mode:
Up to 4 simultaneous analog
Or
2 digital inputs and 2 analog inputs
with automatic sensor identification
8 inputs mode:
Up to 8 simultaneous analog inputs
Or
Up to 2 simultaneous digital inputs and 6 analog inputs
Outputs
RS-232 PC Host Interface at 19,200 bps
USB 1.1 specification compliant (catalog number 529 – USB)
4 Digital Control Outputs
Sampling
Capacity: Up to 100,000 Samples
Analog sampling rate: From 1 Sample/hour to 20,800 Samples/Sec
Digital sampling rate: >200 kHz
Resolution
12-bit (4096 Levels)
Timer Module
Time velocity and acceleration
Range: 0.0014s to 6.5535s
Resolution: 0.1mS
Card width: 0 to 59mm
Distance between gates: 0 to 99cm
Stopwatch
Range: 0 to 99.99s
Resolution: 10mS
Man-machine Interface
•
Full keypad operation enabling manual programming of the MultiLogPRO
•
Graphic LCD
•
Display uses: displaying the logger setup, displaying experiment instructions and
notes and displaying the data measurements in graphs, meters, tables or digital
display
