MultiLab displays the Integral results screen
7. Press

3.6. Data Collection Modes

MultiLab offers you several types of data collection modes. The default mode is TIME
GRAPH where data is collected in a predefined rate and then displayed on a graph
as a function of the time
The other data collection modes are:
LOG DATA – Downloading the last experiment from MultiLogPRO.
EVENTS WITH ENTRY – In this mode you can capture specific data points from
MultiLogPRO stream of data, like taking snapshots of the dynamic process. After
each capture MultiLab prompts you to enter a corresponding X value. When
capturing ends, MultiLab displays the data vs. the manually entered X values.
SINGLE POINT – The system collects 10 samples in 10 seconds and then displays
the average value.
SELECTED EVENT – Much like EVENTS WITH ENTRY except that the data is
displayed as a function of the time (no need to enter X values).
To select a certain data mode:
1. Press
to enter the SELECT MODE menu:
2. Use the Up
then press
to return to the main menu
on the main menu to display the Setup menu then press
and Down
Chapter 3 Working with a TI Calculator
keys to select the collection mode,
119
