The system will collect data for 10 seconds, and then will display the
averaged result:
Press any key to return to the main menu

5. Selected Event

1. From the SELECT MODE menu select EVENTS WITH ENTRY,
then press
2. Press
3. Press
MultiLab displays the sensors' values and the number of captured
samples up to now
4. Press
5. After you finish capturing the data press
6. Use the Up
to display a graph

3.7. Conditioned Data Collection

MultiLogPRO enables you to start the data collection only when a specific
measurement condition has been met (triggering).

1. To Enable Triggering

1. Navigate to the timing setup screen (see Setup MultiLogPRO on
page 110)
2. Press
3. Use the Up
to display the TRIGGER TYPE screen:
to return to the main menu
to start recording
anytime you want to capture a sample
and Down
and Down
Chapter 3 Working with a TI Calculator
keys to select a sensor, then press
keys to select a sensor, then press
