Enter (Start)
Escape
(Stop)

4. Menu Icons and Commands

Start
Press the Enter button to start recording
Setup
Rate – Select recording rate
Samples – Select the total number of recording points
Display – Select the way MultiLogPRO will display the data (at a
rate of up to 10 samples per second):
•
Numeric - Displays the sensor values and the sample number
• Meter - Displays all active sensors in a bar meter display
along with their values
•
Table - Displays the last 6 values of all the active sensors in a
table
•
Graphic - Displays a graphic representation of the sampled
sensors
At rates higher then 10/s the MultiLogPRO will display the data in
a graph at the end of the logging period.
Start – Press the Forward arrow to start recording
Function
•
Minimum – The minimum graph value
•
Maximum – The maximum graph value
•
Average – The graph average
Open
Use the Forward and Backward Arrow buttons to browse the
stored files,
press the Enter button to open a file
Enter the selected menu or select the current menu
option and move to the next menu command or start
recording
Return to the main menu or stop recording
Start recording
Setup MultiLogPRO in 4 steps:
Display statistics of the current data
Open a stored data in graphic display
Chapter 1 MultiLogPRO 11
