1.2. Standalone Operation
One way to program the MultiLogPRO is to use its keypad and screen (the other way
is to use the MultiLab software - see Chapter 2). The keypad allows us to set all the
parameters for data collection, while the LCD screen displays the setting values.
1.2.1.
Backward
Button
On/Off
Buttons
6
Chapter 1 MultiLogPRO
Front Panel Layout
Figure 3: MultiLogPRO front panel
fn
?
LCD Display
Enter/Run
Button
Forward
Button
Escape/Stop
Button
