Fourier MultiLogPRO Installation Manual

Integrating student
computing & science
System Requirements
To work with MultiLab, your system should be equipped with the
following:
Software
• Windows 98, ME, 2000 and XP
• Internet Explorer 5.0 or later (you can install Internet Explorer
5 when you install MultiLab, since it ships with the product)
Hardware
• Pentium II 600 MHz or higher (Pentium 4, 1.6 GHz or higher
is needed for video motion analysis recordings)
• 64 MB RAM (128 MB recommended)
• 10 MB available disk space for the MultiLab application (50
MB to install the supporting applications)
• Free serial or USB port
• To operate the video window your system should be equipped
with a video camera, an available USB port and a compatible
camera driver (installation includes camera driver for the supplied
Web camera)
• To be able to record and play voice comments your system
should be equipped with a sound card, a microphone and a
speaker (the camera supplied by Fourier includes a built-in
microphone)
w w w . f o u r i e r - s y s . c o m
MultiLab
Installation guide
MultiLab PC Installation
Instructions based on WinXP
Warning:
!
Do not connect MultiLogPRO or the supplied Web
camera to the PC before you install the MultiLab
software.
Uninstalling MultiLab
Before installing your new version of MultiLab, uninstall any older
versions of the program.
NOTE: Uninstalling removes program files only. Project files and
worksheets you created or modified in MultiLab will remain
on your system and there is no need to create backups.
To uninstall the software
1. From the Start menu select Settings then click Control Panel.
2. Double click Add or Remove Programs.
3. Select MultiLab from the list of programs.
4. Click Remove.
5. In the following dialog box, click Yes to confirm that you want
to remove MultiLab.
6. When uninstall is complete you will be prompted to restart the
computer. Select Yes.
Installing MultiLab
1. Close all open programs.
2. Insert the CD labeled MultiLab into your PC's CD-ROM drive.
3. Installation will begin automatically. You will first be prompted
to install MultiLab. Click Next to begin installation.
If auto run is not working, open My Computer and click
on the CD drive folder (d: drive in most cases) and double-
click on the setup icon, then proceed as above.
4. Enter user name and company name in the Customer
Information window. It is also recommended to install for all
users. Click Next.
5. In the Choose Destination Location window, the default
folder where MultiLab will be installed is C:\Program Files\Fourier
Systems\MultiLab. Click Browse to change this folder location,
or click Next.
6. MultiLab installation will proceed, followed by installation of
the D-Link Web cam driver. After installation is complete, you
are prompted to restart the computer. It is recommended to
restart the computer now.
™
