3. Setup the MultiLogPRO

1. Click Setup Wizard
2. Follow the instructions in the Setup Wizard (see page 54)

4. Start Recording

Click Run on the toolbar to start recording.
If the recording rate is 100 measurements per second or less, MultiLab automatically
opens a graph window displaying the data in real time, plotting it on the graph as it is
being recorded. If the recording rate is higher than 100/s, the data will be
downloaded and displayed automatically once the data recording is finished.
You can stop recording anytime by clicking Stop
2.3.2.

Data Recording Options

To set the behavior of the data display when you start a new recording session, click
on the down arrow next to the Run button

1. Single Measurement

MultiLab will open a new project file every time you start a new recording session.

2. Replace

MultiLab will display the new data set in place of the old one. The project's old data
sets will still be available in the same project file. They will be listed in the Data Map
and you can add them to the display at any time.

3. Add

MultiLab will add the new data set to the graph in addition to the old ones.
Note: A maximum of 8 data sets can be displayed on the graph at the same time.
2.3.3.

Manual Sampling

Use this mode for:
• Recordings or measurements that are not related to time.
•
Situations in which you have to stop recording data after each sample
obtained, in order to change your location, or any other logging
parameter (Note: During the experiment no changes can be made to
the MultiLogPRO's configuration).
To start an experiment using manual data logging, set the rate to manual and click
Run once to start the data recording, then press the Enter button each time
you want to collect a sample.
32 Chapter 2 MultiLab Software
on the main toolbar
on the toolbar.
, and select one of the following:
