Controls, Indicators, and Connectors
Keypad

Rear Panel

Bright
ness
Ethernet port
USB connectors
On/Off switch
RS232 port
Power connector
Brightness control
Ethernet port
USB connectors
On/Off switch
3-2
Enables you to enter commands for the analyzer. Refer to
Pycnometer Keypad, page
keypad.
Enables you to adjust the brightness of the display.
Insert a small-blade screwdriver into the opening. Rotate the
screwdriver until you feel it engage in the slot, then turn
clockwise to darken and counterclockwise to lighten.
This port can be used to connect to a network enabling you to
be notified via e-mail of analysis completion, and to monitor
analysis results using a web browser. A straight-through or
cross-over ethernet cable can be used since the analyzer will
adapt to either type.
For attaching external devices, such as a printer, bar code
reader, or keyboard. This connector is also used to install
software upgrades.
For turning the analyzer on and off
3-4 for a description of the
AccuPyc II 1340
Analy-
sis
mod-
Gas inlet port
