The display consists of four lines; it provides information about the analyzer and the current operation.
This is an example of the display when the analyzer is in an idle state, referred to in this documentation
as the Reload prompt. During operations, different types of information are shown in lines two, three,
and four. Line one always contains the same information.
First line
Second line
Third line
3-8
Unit[n] SN1234 10 cm3
X - X - X
Reload
P = (current pressure)
Displays the unit number, serial number, and nominal cell
volume of the selected unit. You can have up to five analysis
modules attached; all six will be controlled by the initial
module containing the controls (keypad and display).
At the Reload prompt (shown above), manual control, or an
automatic operation, this line contains three characters,
separated with dashes. The first character represents the Fill
valve, the second represents the Expand valve, and the third
represents the Vent valve. Valve states are as follows:
X = closed
O = open
During user interface, this line shows the command you are
currently using. For example; it displays Analysis
Parameters when you are entering analysis parameters.
Displays status of the current operation, or Reload when in
an idle state. When the Reload prompt is displayed, this line
may also contain an asterisk (*), indicating there is a message
(or messages) in the queue. Refer to
page A-1 for information on viewing and clearing these mes-
sages, and for a list of the error messages that may be seen.
During certain functions (such as Set Up), this line contains a
prompt for additional information.
