The AccuPyc is a standard DTE device. The RS-232 port on the rear panel of the AccuPyc can
be used to attach an analytical balance for transfer of sample weight, or for transmitting data
through a serial line to a computer.
The pin assignment for the RS-232 port is shown in the following table; be sure your receiving
device is configured to interface with these assignments. Any signals that are not listed in the
table will be ignored by the AccuPyc.
Pin
2
3
4
5
6
The AccuPyc uses the DTR and DSR signals for hardware flow control. Be sure that your
serial device provides these signals. For example; if attaching to a PC (also a DTE device), use
a null modem cable which includes the signals designated in the above table.
If you experience a problem with transmission, ensure that the signals are set up properly. If
the signals are correctly configured, contact the receiving device manufacturer for assistance.
Feb 07
H. RS-232 PIN ASSIGNMENT
Signal
RXD Receive data
TXD Transmit data
DTR Data terminal ready
GND Ground
DSR Data set ready
Description
Appendix H
Data Direction
Into AccuPyc
From AccuPyc
From AccuPyc
—
Into AccuPyc
H-1
