Goodrive300-21 integrated machine for air compressor
"○" indicates that the value of the parameter can be modified when the inverter is in stopped or
running state.
"◎" indicates that the value of the parameter cannot be modified when the inverter is in running state.
"●" indicates that the value of the parameter is detected and recorded, and cannot be modified.
(The inverter automatically checks and constrains the modification of parameters, which helps
prevent incorrect modifications.)

5.1 Function code instruction

Function
code
P00.00 Speed control mode
Channel of running
P00.01
commands
Communication
P00.02 mode of running
commands
Max. output
P00.03
frequency
Upper limit of
P00.04
running frequency
Lower limit of
P00.05
running frequency
Setting channel of A
P00.06
frequency command
Setting channel of B
P00.07
frequency command

5 Function description

Name
0: Sensorless vector control (SVC) mode 0
(for AM, SM)
1: SVC mode 1 (for AM)
2: V/F control
AM-asynchronous motor
SM-synchronous motor
0: Keypad (the indicator is off)
1: Terminal (the indicator blinks)
2: Communication (the indicator is on)
0: MODBUS communication channel
1–3: Reserved
P00.04–600.00Hz (400.00Hz)
P00.03–P00.05 (Max. frequency)
Setting range: P00.03–P00.06
0.00Hz–P00.04
frequency)
0: Keypad
1: Analog P1-setting
2: Reserved
3: Analog P2-setting
4: Reserved
5: Reserved
6: Multi-step speed running
7: PID control
8: MODBUS communication
Description
(Upper limit
- -
23
Function description
Default Modify
0
0
0
50.00Hz
50.00Hz
of running
0.00Hz
0
2
◎
○
○
◎
○
○
○
○
