INVT Goodrive300-21 Series Operation Manual page 38

Goodrive300-21 integrated machine for air compressor
Function
code
Output terminal
P06.05
polarity selection
P06.06 Y switch-on delay 0.000–50.000s
P06.07 Y switch-off delay 0.000–50.000s
P06.08 Reserved
P06.09
Reserved
TAC1 switch-on
P06.10
TAC1 switch-off
P06.11
TAC2 switch-on
P06.12
TAC2 switch-off
P06.13
Name
12: Ready for running
13: Pre-exciting
14–19: Reserved
20: External fault is valid
21–22: Reserved
23: Modbus communication virtual terminal
output
24–25: Reserved
26: Special for oil pump (for blower)
27: Auxiliary motor start/stop control (for air
compressor)
28: Solenoid valve control output (for air
compressor)
29: Cooling fan control of main motor (for air
compressor)
30: Reserved
The function code is used to set the polarity of
output terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT3
TAC2
Setting range: 0–0xF
0.000–50.000s
0.000–50.000s
0.000–50.000s
delay
0.000–50.000s
delay
0.000–50.000s
delay
0.000–50.000s
delay
Description
BIT2 BIT1
Reser
TAC1
ved
- -
34
Function description
Default Modify
0
BIT0
Y
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
○
○
○
○
○
○
○
○
○
