Goodrive300-21 integrated machine for air compressor
Function
code
Delay time of
P08.18
automatic start-up
Low voltage
P08.19 frequency-limit
running time
Counting mode of
P08.26
maintenance time
PID reference
P09.00
PID reference
P09.01 preset through
keypad
PID feedback
P09.02
PID output
P09.03 characteristics
selection
Name
0.0–6000.0s
0.0–6000.0s
0–1
0: Counting during motor running
1: Counting during motor running and sleeping
0: Keypad (P09.01)
1: Analog P1-reference
2: Reserved
3: Analog P2-setting
4: Reserved
source 5: Multi-step running
6: MODBUS communication
7–9: Reserved
10:
compressor-specific function
-100.0%–100.0%
0: Analog P1-feedback
1: Reserved
2: Analog P2-feedback
3: Reserved
source 4: MODBUS communication feedback
5–7: Reserved
8:
compressor-specific function
0: PID output is positive. When the feedback
signal is greater than the PID reference value,
the output frequency of the inverter will
decrease to balance the PID. Example: PID
control on strain during unwinding.
1: PID output is negative. When the feedback
signal is greater than the PID reference value,
the output frequency of the inverter will
Description
Pressure setting
Pressure feedback
- -
39
Function description
Default Modify
60.0s
60.0s
0
0
for air
0.0%
0
for air
0
○
○
○
○
○
○
○
