INVT Goodrive300-21 Series Operation Manual page 23

Goodrive300-21 integrated machine for air compressor
Function code Configuration value
P00.00
P00.01
P00.06
P01.15
P03.27
P09.00
P09.02
P11.15
P05.01
P05.10
P05.02
P06.03
P06.04
P05.32
Step 4 In system configuration interface, click "System parameters setting". When S1 functions as
emergency-stop switch, select NO or NC based on the polarity of the emergency-stop switch. When
S2 functions as motor overtemperature switch, select NC based on the polarity.
Set pressure sensor parameter, temperature sensor parameter and specialized function parameter
according to system sensor configuration condition. Then, click "Return" to enter system configuration
page.
0: Vector control (SM)
0 or 2 2: VF control (AM)
Select according to the motor type.
2 2: Communication
7 Main frequency PID control setting
35.00 Stop frequency: 35Hz
1 Vector control speed displayed by set value
10 Pressure setting for air compressor
8 Pressure feedback for air compressor
0 No speed deviation protection
6 Coast to stop
3 Reverse S1, S2 terminal polarities
46 External fault (motor over-temperature)
28 Solenoid valve control output
29 Fan start/stop control
2.04 P1 lower limit corresponds to voltage 2.04V
Figure 4-13 System parameter configuration interface
Description
- -
19
Commissioning guidelines
