INVT Goodrive300-21 Series Operation Manual page 18

Goodrive300-21 integrated machine for air compressor
Through hole of
controlling cable
Through hole of
optional parts
cable
Through hole of
ground wire
AC power
R, S, T through
hole
Figure 4-4 Bottom view for 45–90kW
Figure 4-5 Front wiring diagram for 45–90kW
Main motor
U1, V1, W1 through
hole
- -
14
Commissioning guidelines
Through hole of
controlling cable
Fan
U2, V2, W2, ground wire
through hole
Ground wire
through hole
Ventilation hole at the
bottome of the integrated
machine
