Floor-Mounting Dimension (Without Top Cover); Product Weight And Packaging Dimension - INVT Goodrive300-21 Series Operation Manual

Goodrive300-21 integrated machine for air compressor
A.3 Floor-mounting dimension (without top cover)
Table A-4 Dimension for 220V 7.5–45kW/380V 15–90kW (unit: mm)
Model
220V 7.5–11kW
380V 15–22kW
220V 15–18.5kW
380V 30–37kW
220V 22–45kW
380V 45–90kW
A.4 Product weight and packaging dimension
Product weight
220V 7.5–11kW/380V 15–22kW
(integrated machine)
POWER RUN FAULT
Front view
Figure A-4 Diagram for 220V 7.5–45kW/380V 15–90kW
W1 W2 H1
278 265 555
328 315 604
404 388 812
Bottom view
D1 D2 D3
180 148 10
190 158 15
250 160 44
N.W(kg) G.W (kg)
15 18
- -
79
Product dimension
Leftside view
Installation
hole diameter specification
6
6
9
Packaging dimension (mm)
515x385x320
Screw
M5
M5
M8
