Goodrive300-21 integrated machine for air compressor
Function
code
High frequency
P13.12 compensation
coefficient
P14.00 communication
address
Communication
P14.01
baud rate
P14.02 Data bit check
Communication
P14.03
response delay
Communication
P14.04
timeout time
Transmission error
P14.05
processing
Communication
P14.06
processing action
Name
Valid when the motor speed exceeds the rated
speed. If oscillation occurred to the motor,
adjust this parameter properly.
Setting range: 0.0–100.0%
Local
1–247; 0 indicates a broadcast address
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
0–200ms
0.0 (invalid), 0.1–60.0s
0: Report an alarm and coast to stop
1: Keep running without reporting an alarm
2: Stop in enabled stop mode without
reporting an
communication mode)
3: Stop in enabled stop mode without
reporting an alarm (applicable to any mode)
0x00–0x11
LED ones: Writing operation
0: Respond to write operations
1: Not respond to write operations
LED tens: Communication encryption
0: Disabled
1: Enabled
Description
alarm (applicable
- -
44
Function description
Default Modify
50.0%
2
4
1
5
0.0s
only to 0
0x00
○
○
○
○
○
○
○
○
