INVT Goodrive300-21 Series Operation Manual page 17

Goodrive300-21 integrated machine for air compressor
R, S, T, ground wire through hole
Through-hole of
controlling cable
Through-hole of
optional parts cable
Data collection
terminal
shielded cable
grounding
Controlling
cable
Controlling cable
AC power
Figure 4-2 Bottom view for 15–22kW
AC power cable
Figure 4-3 Front wiring diagram for 15–22kW
Main motor
U1, V1, W1, ground wire through hole
Main motor Fan cable
cable
- -
13
Commissioning guidelines
Through-hole of controlling cable
Fan
U2, V2, W2, ground wire through hole
Ventilation hole at the bottom of
integrated machine
Controlling cable
Controlling cable
