INVT Goodrive300-21 Series Operation Manual page 30

Goodrive300-21 integrated machine for air compressor
Function
code
Leakage inductance
P02.08
of AM 1
Mutual inductance
P02.09
of AM 1
No-load current of
P02.10
Magnetic saturation
P02.11 coefficient 1 of iron
core of AM 1
Magnetic saturation
P02.12 coefficient 2 of iron
core of AM 1
Magnetic saturation
P02.13 coefficient 3 of iron
core of AM 1
Magnetic saturation
P02.14 coefficient 4 of iron
core of AM 1
Rated power of SM
P02.15
Rated frequency of
P02.16
Number of pole
P02.17
pairs of SM 1
Rated voltage of SM
P02.18
Rated current of SM
P02.19
Stator resistance of
P02.20
Direct-axis
P02.21
inductance of SM 1
Quadrature-axis
P02.22
inductance of SM 1
Counter-emf
P02.23
constant of SM 1
Name
0.1–6553.5mH
0.1–6553.5mH
0.1–6553.5A
AM 1
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.1–3000.0kW
1
0.01Hz–P00.03 (Max. output frequency)
SM 1
1–50
0–1200V
1
0.8–6000.0A
1
0.001–65.535Ω
SM 1
0.01–655.35mH
0.01–655.35mH
0–10000
Description
- -
26
Function description
Default Modify
Model
○
depended
Model
○
depended
Model
○
depended
◎
80.0%
◎
68.0%
◎
57.0%
◎
40.0%
Model
◎
depended
◎
50.00Hz
◎
2
Model
◎
depended
Model
◎
depended
Model
○
depended
Model
○
depended
Model
○
depended
○
350
