Goodrive300-21 integrated machine for air compressor
Function
code
P05.05 Function of S5
P05.06 Reserved
Input terminal
P05.10
polarity
Digital input filter
P05.11
P05.14 S1 switch-on delay 0.000–50.000s
P05.15 S1 switch-off delay 0.000–50.000s
P05.16 S2 switch-on delay 0.000–50.000s
P05.17 S2 switch-off delay 0.000–50.000s
Name
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10–24: Reserved
25: Pause PID control
26–39: Reserved
40: Clear electricity consumption
41: Keep electricity consumption
42: Air filter block signal
43: Oil filter block signal
44: Separator block signal
45: Splitter block signal
46: External fault 1
47: External fault 2
48: Fan running control signal
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
51–63: Reserved
The function code is used to set the polarity of
input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT4
S5
Setting range: 0x000–0x1FF
0.000–1.000s
time
Description
BIT8 BIT7 BIT6
Rese Rese Rese
rved rved rved
BIT3 BIT2 BIT1
S4 S3 S2
- -
31
Function description
Default Modify
0
BIT5
0x000
Rese
rved
BIT0
S1
0.200s
0.000s
0.000s
0.000s
0.000s
◎
○
○
○
○
○
○
