INVT Goodrive300-21 Series Operation Manual page 52

Goodrive300-21 integrated machine for air compressor
Function
code
P17.22 PT2 input voltage
P17.23 PID reference value
P17.24 PID feedback value
P17.25 Motor power factor -1.00–1.00
P17.26 Duration of this run 0–65535m
ASR controller
P17.28
Magnetic pole angle
P17.29
P17.30
compensation of SM
P17.36 Output torque
P17.38 PID output
Air compressor
P18.00
control mode
Name
Displays the analog input voltage value of PT2
channel. Connect PT100 thermal resistor
temperature sensor in air compressor mode,
and different resistance value will be
generated under different temperature.
Different resistance value corresponds to
different input voltage. Therefore, the input
voltage value can correspond to the
corresponding detection temperature. The
input voltage P18.32-P18.33 corresponds to
-20° C-150° C.
Range: 0.00–10.00V
Displays the set value of exhaust pressure
signal. 100.0% corresponds to the upper limit
value of exhaust pressure sensor P18.04 (If
P18.37=1, 100% corresponds to P18.38).
Range: -100.0–100.0%
Displays detection value of exhaust pressure
signal.
Range: -100.0–100.0%
-300.0%–300.0% (of the motor rated current)
output
0.0–360.0
of SM
Phase
-180.0–180.0
-3000.0Nm–3000.0Nm
Displays PID control adjustment output value
of exhaust pressure signal. 100.0%
corresponds to maximum output frequency
P00.03.
Setting range: -100.00–100.00%
0: Disable
1: Air compressor control mode
Note: When P18.00=1, P19 group air
compressor state check group is valid.
Description
- -
48
Function description
Default Modify
●
0.00V
●
0.0%
●
0.0%
●
0.0
●
0m
●
0.0%
●
0.0
●
0.0
●
0.0Nm
●
0.00%
◎
0
