Goodrive300-21 integrated machine for air compressor
B.1.4 Dimension of contactor component
Fix this part with M4 screw
4
Figure B-2 Installation diagram of fuse pedestal
35mm standard guide rail installation
Figure B-3 Contactor dimension (unit: mm)
12
44.4
55.5
Figure B-4 Dimension of conversion terminals (unit: mm)
5
M4 fixation screw
8
5
（ include dimension of transparent cover ）
- -
83
Optional parts
19.5
