INVT Goodrive300-21 Series Operation Manual page 14

Goodrive300-21 integrated machine for air compressor
Category
input
Digital input
Digital output
Communication 485+, 485-
PE/CGND
Solenoid valve
Note: The connection terminal of solenoid valve/contactor cannot be connected to other load. When
the power of solenoid valve and contactor coil exceeds 30W, the power frequency transformer inside
the integrated machine needs to be customized or connected with external 220V power
independently.
Symbol Terminal name
P1- analog signal 1
P2+
Pressure
analog signal 2
P2-
S1 Digital input 1
S2 Digital input 2
S3 Digital input 3
S4 Digital input 4
S5 Digital input 5
Digital
COM
reference GND
Y1 Digital output
RS485
communication
PE/CGND
TA1 Solenoid valve
TC1 coil
TA2
Contactor coil
TC2
Description
4–20mA/2–10V corresponds to 0–1.6MPa;
P1 is switched by jumper J7 while P2 by J8
2. Input impedance: 20kΩ for voltage input;
500Ω for current input
3. Resolution rate: min. 5mV
4. Error: ±1%, 25° C
1. Internal impedance: 3.3kΩ
2. 12–30V voltage input is acceptable
3. Max. input frequency: 1kHz
1. Switch capacity: 50mA/30V
2. Output frequency range: 0–1kHz
RS485 communication terminals, using the
Modbus RTU protocol
PE: When select PE by J9, it can be used in
connection terminal
shielded cable;
CGND: When select CGND by J10, it can be
used in connection
communication reference GND or shielded cable.
1. Contact capacity: 3A/AC250V, 1A/DC30V
2. Cannot used as high frequency switch output
3. Voltage of power supply: 220V/110V, select
via CN7/CN8
4. Max. output
frequency transformer: 30W
- -
10
Installation guidance
of 485 communication
terminal of
power of internal
485
power
