Examine Perpendicularity in the Y Direction
Examine Perpendicularity in the X Direction
Examine the Alignment of the Carousel Door Opening

Prepare the Machine

1. Push the tool tray toward the spindle.
Figure 6: Tool tray moved in toward the spindle.
2. Verify that the linear bearing on the ATC is flush with the ATC main assembly.
Figure 7: Linear bearing flush with the ATC main assembly.
©Tormach® 2020
Specifications subject to change without notice.
Page 9
TD10560: Owner's Guide: M ATC Retrofit for PCNC 770 Series 3 (1220A)
