TECHNICAL DOCUMENT
5. Use a small, flat-blade screwdriver to connect the following wires to the J10 connector:
Wire 408 to pin 3
l
Wire 403 to pin 4
l
Wire GND to pin 5
l
6. Plug the J10 connector back in the ATC board.
7. Close the lid on the ATC main assembly and lock it.

Verify the Installation

1. Power on the machine and the PathPilot controller.
a. Turn the Main Disconnect switch to ON on the side of the electrical cabinet.
b. Twist out the Emergency Stop button on the operator panel, which enables movement to the machine
axes and the spindle.
c. Press the Reset button on the operator panel.
d. Bring the machine out of reset and reference it.
IMPORTANT!
Automatic Tool Changer. If you don't, there's a risk that the ATC could become inoperable.
2. If you have not yet done so, you must make sure that the PathPilot controller is updated to the latest version
of PathPilot: From the Status tab, select Update. Then, follow the on-screen instructions.
3. From the PathPilot interface, on the Settings tab, select the ATC radio button.
Figure 27: ATC radio button on the Settings tab.
The ATC tab appears in the PathPilot interface.
Note: If prompted, you may need to update the firmware for the ATC. Follow the on-screen
instructions.
©Tormach® 2020
Specifications subject to change without notice.
You must update your controller to the latest version of PathPilot before operating the
Page 26
TD10560: Owner's Guide: M ATC Retrofit for PCNC 770 Series 3 (1220A)
tormach.com
