Install the Air Cylinder
Mount the Automatic Tool Changer (ATC) Bracket
Install the Main Assembly
Level the Automatic Tool Changer (ATC)
Prepare the Machine
Examine Perpendicularity in the Y Direction
Examine Perpendicularity in the X Direction
Examine the Alignment of the Carousel Door Opening
Make Air Connections
Make Electrical Connections
Rewire the Power Drawbar Board
Connect the ATC Legacy Adapter Cable
Rewire the ATC Board
Verify the Installation
Adjust the Power Drawbar
Adjust the Drawbar Tension
Adjust the Initial Setup

Install the Air Cylinder

1. Attach the air cylinder on to the ATC main assembly.
Figure 1: Putting the air cylinder into the ATC main assembly.
©Tormach® 2020
Specifications subject to change without notice.
Page 5
TD10560: Owner's Guide: M ATC Retrofit for PCNC 770 Series 3 (1220A)
5
6
8
8
9
10
11
12
14
15
15
17
25
26
28
28
29
