Tormach Automatic Tool Changer Owner's Manual page 3

TECHNICAL DOCUMENT
BEFORE YOU BEGIN
1. If there's a tool holder in the spindle, remove it.
2. Remove any accessories or fixtures from the machine table.
3. Center the machine table: from the PathPilot interface, in the MDI Line DRO field, type G20 G53 G1 X7
Y-3.75 Z0 F20. Then select the Enter key.
IMPORTANT!
operating the Automatic Tool Changer. If you don't, there's a risk that the ATC could become
inoperable.
4. Update your controller: From the Status tab, select Update. Then, follow the on-screen instructions. Once
the controller is updated to the latest version of PathPilot, go to Step 5.
WARNING! Electrical Shock Hazard: You must power off the machine before making any electrical
connections. If you don't, there's a risk of electrocution or shock.
5. Power off the machine and the PathPilot controller.
a. Push in the Emergency Stop button on the operator panel, which removes power to motion control.
b. From the PathPilot interface, select Exit.
c. Turn the Main Disconnect switch to OFF on the side of the electrical cabinet.
©Tormach® 2020
Specifications subject to change without notice.
You must update your controller to the latest version of PathPilot before installing and
Page 3
TD10560: Owner's Guide: M ATC Retrofit for PCNC 770 Series 3 (1220A)
tormach.com
