- Page 1 TECHNICAL DOCUMENT Version 0920A INSTALLATION GUIDE 15L SLANT-PRO LATHE MANUAL 5C DRAWTUBE Page 1 Specifications subject to change without notice. ©Tormach® 2020...
- Page 2 Screw, Socket Head Cap, M6 × 1 - 22 (PN 31843) Thrust Bearing (50406) Note: If any items are missing, we can help. Email support@tormach.com to contact Tormach Technical Support for guidance on how to proceed. REQUIRED TOOLS This procedure requires the following tools. Collect them before you begin.
- Page 3 5. Remove the encoder cover's three screws with a Phillips screwdriver, and set aside the encoder cover and its screws 6. Identify the spindle bore cover above the rotary encoder. Page 3 ©Tormach® 2020 tormach.com Specifications subject to change without notice. TD10774: Installation Guide: 15L Slant-PRO Lathe Manual 5C Drawtube (0920A)
- Page 4 1. Remove any burrs on the face of the spindle pulley with a machinist's stone. Burrs could cause runout. Figure 3: Face of the spindle pulley on the left side of the machine. Page 4 ©Tormach® 2020 tormach.com Specifications subject to change without notice.
- Page 5 4. Put the base of a magnetic dial indicator on either side of the spindle pulley. Verify that the magnetic dial indicator touches the adapter spacer. Page 5 ©Tormach® 2020 tormach.com Specifications subject to change without notice. TD10774: Installation Guide: 15L Slant-PRO Lathe Manual 5C Drawtube (0920A)
- Page 6 10. Put the base of a magnetic dial indicator on either side of the spindle pulley. Verify that the magnetic dial indicator touches the drawtube standoff. Page 6 ©Tormach® 2020 tormach.com Specifications subject to change without notice. TD10774: Installation Guide: 15L Slant-PRO Lathe Manual 5C Drawtube (0920A)
- Page 7 Twist out the Emergency Stop button on the operator box, which enables movement to the machine axes and the spindle. c. Press the Start button on the operator box. Page 7 ©Tormach® 2020 tormach.com Specifications subject to change without notice. TD10774: Installation Guide: 15L Slant-PRO Lathe Manual 5C Drawtube (0920A)
